Tie Rod
Heavy-Duty Threaded Rod for Formwork & Construction Stability
Our Tie Rods are high-strength, fully threaded steel bars designed to provide tension support in concrete formwork and shuttering systems. Built to endure extreme loads and environmental conditions, they are an essential component in reinforced concrete construction, tunnel formwork, bridgework, and heavy civil engineering projects.
✅ High Tensile Strength: Made from premium-grade carbon steel for superior load-bearing capacity.
✅ Fully Threaded Design: Enables flexible length adjustment and easy compatibility with wing nuts, plates, and couplers.
✅ Corrosion-Resistant Options: Available in Hot-Dip Galvanized, Black Steel, and Epoxy Coated finishes.
✅ Standard and Custom Sizes: Offered in common diameters (15/17mm) and cut-to-length options for large-scale projects.
✅ Reusable & Durable: Engineered for multiple cycles without compromising thread integrity.
Specification | Details |
|---|---|
Material | High-Strength Carbon Steel |
Common Diameter | 15 mm, 17 mm |
Length | 1m, 2m, 3m, or custom lengths |
Thread Pitch | 10mm per turn (standard for formwork) |
Tensile Strength | Up to 180 kN (depending on size and grade) |
Surface Finish | Black, Galvanized, or Epoxy Coated |
Standards | DIN / ISO / BS / ASTM |
Formwork and shuttering for concrete columns, walls, and slabs
Civil engineering and infrastructure projects (bridges, dams)
Retaining walls and temporary structures
Tunnel and shaft formwork
Scaffold anchoring and tensioning systems
✔️ UAE Stock Availability: Immediate delivery in Dubai, Abu Dhabi, Sharjah, Ajman & beyond
✔️ High Load Capacity & Reusability: Perfect for contractors who demand durability and value
✔️ Compatible Accessories Available: Wing nuts, anchor plates, water stoppers, couplers, and cones
✔️ Bulk Order Support: Ideal for major construction companies and infrastructure contractors
✔️ Custom Cut & Coating Services: Tailored lengths and finishes based on your project requirements
Q: What is the standard tie rod size used in formwork?
A: 15/17 mm diameter tie rods are the most commonly used in formwork systems worldwide.
Q: Can tie rods be reused?
A: Yes. Our tie rods are manufactured for multiple uses if cleaned and maintained properly after each cycle.
Q: Do you supply tie rod accessories?
A: Yes. We provide wing nuts, anchor plates, tie rod connectors, and water stops.
Q: Do you offer delivery outside the UAE?
A: Yes. In addition to local UAE delivery, we ship across the GCC and Middle East upon request.
